3) Check PC's subnet to make sure it is routable to the radio's IP address.
4) Ensure snmpd is enabled
5) If a firmware upgrade was just performed and one file did not load properly and the
system rebooted, you will lose management. Please call Technical Support for
further assistance.

No Radio Management connection over the link

1) Verify the In-Band management is set up properly - Check to see if the IP
configuration is correct, the VLAN ID is set and matches on both ends, and that IBM
is enabled.

T1/E1 Ports not passing traffic

1) Mismatched T1 ports, since the T1 ports are port mapped T1 port 1 on IDU one must
be connected to T1 port 1 on the second IDU.
2) Ensure the port is enabled using the datapath command. The datapath must be set
to Eth + T1 or Eth+E1 , the config saved, and the system rebooted at both sides.
3) Verify pin outs of the T1/E1 RJ45 connector
4) GigaPlus-Key-PDH License Key not activated
If there are still problems please contact Technical Support at 858-391-0010 or Email at
techsupport@trangosys.com
Before calling please make sure you have the following information.
 Serial Number
 Description of the problem
 Steps taken so far to resolve the problem
 Commissioning log
Trango Systems, Inc. GigaPlus User Manual Rev 3.1
136
