Receiver Maximum Input

The maximum receiver RF level, measured by RSSI, is depicted in Table 9 below. If the
RSSI value is higher than listed for the modulation being used, packet loss may result.
When operating short range links with a high receiver input level, always make sure that
the transmitter power is adjusted down from the maximum to ensure the levels shown
below are not exceeded, or active ATPC with a target rssi that is at least several dB
below the levels shown to provide a safety margin.
Trango Systems, Inc.
Modulation Level
256 QAM
128 QAM
64QAM
32QAM
16QAM
QPSK

Table 9 Max Receive Level Input

GigaPlus User Manual Rev 3.1
Max RSSI
-24 dBm
-22 dBm
-20 dBm
-18 dBm
-16 dBm
-14 dBm
