1+1 Hot Standby Link Protection

Parameter
Failover Time
Guard Time

Power

Parameter
Input Voltage Range
Power Consumption

User Interfaces

Description
Ethernet Traffic Ports and/or In
Band Management (IBM)
Out of Band Management (OBM)
T1/E1 Ports 1-8
Alarm Inputs (2)
Alarm Outputs (2)
PowerInput
Console/Craft Port
1+1 Redundancy Port
RSSI Alignment
Reset IP/Config
Reboot System
Antenna
Trango Systems, Inc.

Specification

150 mSec typical
User configurable 10 to 60 seconds
-40 to -72 VDC
IDU: Max 35 Watts with all ports active
ODU: Typical 25 Watts, max 50 Watts
ETH1 and ETH2: RJ45 Jack - 10/100/1000BaseT
ETH3 and ETH4: SFP - 1000BaseT for SFP Module:
SFP-GigE- C (1000BaseT)
SFP-GigE-S (1000BaseLX Single Mode Fiber)
SFP-GigE-M (1000BaseLX Multimode Fiber)
RJ45 Jack- 10/100BaseT
RJ45 Jack
0-5 Volt high impedance CMOS level
DB9 Female, 50 Volt 1 Amp rated, Dry contact
3 Position latching screw terminal Block with locking screws
DB9 Male(requires Serial Cable)
RJ45 Jack (requires CBLDAT-RIU3)
BNC-Female (CBLDAT-RSSI recommended)
Momentary Push Button on IDU front panel
Momentary Push Button on IDU front panel
Slip-Fit Circular Waveguide for 7-40 GHz
Slip-Fit Rectangular Waveguide for 6 GHz
GigaPlus User Manual Rev 3.1
Specification
Specification
