Outdoor Unit
Part Numbers
HP ODUs, – 26 GHZ
HP2-26-0800-1A ODU, HP2 26Ghz, ETSI TR800, 1A
HP2-26-0800-1B ODU, HP2 26Ghz, ETSI TR800, 1B
HP-26-0800-1A ODU, HP 26Ghz, ETSI TR800, 1A
HP-26-0800-1B ODU, HP 26Ghz, ETSI TR800, 1B
HP2-26-1008-1A ODU, HP2 26Ghz, ETSI TR1008, 1A
HP2-26-1008-1B ODU, HP2 26Ghz, ETSI TR1008, 1B
HP2-26-1008-2A ODU, HP2 26Ghz, ETSI TR1008, 2A
HP2-26-1008-2B ODU, HP2 26Ghz, ETSI TR1008, 2B
HP2-26-1008-3A ODU, HP2 26Ghz, ETSI TR1008, 3A
HP2-26-1008-3B ODU, HP2 26Ghz, ETSI TR1008, 3B
HP-26-1008-1A ODU, HP 26Ghz, ETSI TR1008, 1A
HP-26-1008-1B ODU, HP 26Ghz, ETSI TR1008, 1B
HP-26-1008-2A ODU, HP 26Ghz, ETSI TR1008, 2A
HP-26-1008-2B ODU, HP 26Ghz, ETSI TR1008, 2B
HP-26-1008-3A ODU, HP 26Ghz, ETSI TR1008, 3A
HP-26-1008-3B ODU, HP 26Ghz, ETSI TR1008, 3B
HP ODUs, – 28 GHZ
HP-28-1008-1A ODU, HP 28Ghz, ETSI TR1008, 1A
HP-28-1008-1B ODU, HP 28Ghz, ETSI TR1008, 1B
HP-28-1008-2A ODU, HP 28Ghz, ETSI TR1008, 2A
HP-28-1008-2B ODU, HP 28Ghz, ETSI TR1008, 2B
HP2-28-1008-1A ODU, HP 28Ghz, ETSI TR1008, 1A
HP2-28-1008-1B ODU, HP 28Ghz, ETSI TR1008, 1B
HP2-28-1008-2A ODU, HP 28Ghz, ETSI TR1008, 2A
HP2-28-1008-2B ODU, HP 28Ghz, ETSI TR1008, 2B
HP2-28-450-1A ODU, HP 28Ghz, ANSI TR450 1A
HP2-28-450-1B ODU, HP 28Ghz, ANSI TR450 1B
HP2-28-450-2A ODU, HP 28Ghz, ANSI TR450 2A
HP2-28-450-2B ODU, HP 28Ghz, ANSI TR450 2B
HP2-28-450-3A ODU, HP 28Ghz, ANSI TR450 3A
HP2-28-450-3B ODU, HP 28Ghz, ANSI TR450 3B
HP ODUs, – 32 GHZ
HP-32-0812-1A ODU, HP 32Ghz, ETSI TR812, 1A
HP-32-0812-1B ODU, HP 32Ghz, ETSI TR812, 1B
HP-32-0812-2A ODU, HP 32Ghz, ETSI TR812, 2A
HP-32-0812-2B ODU, HP 32Ghz, ETSI TR812, 2B
HP ODUs – 38 GHZ
HP1-38-0700-1A ODU, HP 38Ghz, ANSI/ETSI TR700, 1A
HP1-38-0700-1B ODU, HP 38Ghz, ANSI/ETSI TR700, 1B
HP1-38-0700-2A ODU, HP 38Ghz, ANSI/ETSI TR700, 2A
HP1-38-0700-2B ODU, HP 38Ghz, ANSI/ETSI TR700, 2B
HP1-38-0700-3A ODU, HP 38Ghz, ANSI/ETSI TR700, 3A
HP1-38-0700-3B ODU, HP 38Ghz, ANSI/ETSI TR700, 3B
HP1-38-0700-4A ODU, HP 38Ghz, ANSI/ETSI TR700, 4A
HP1-38-0700-4B ODU, HP 38Ghz, ANSI/ETSI TR700, 4B
HP2-38-1260-1A ODU, HP2 38Ghz ETSI TR1260, 1A
HP2-38-1260-1B ODU, HP2 38Ghz ETSI TR1260, 1B
HP2-38-1260-2A ODU, HP2 38Ghz ETSI TR1260, 2A
HP2-38-1260-2B ODU, HP2 38Ghz ETSI TR1260, 2B
HP1-38-1260-1A ODU, HP 38Ghz, ANSI/ETSI TR1260, 1A
HP1-38-1260-1B ODU, HP 38Ghz, ANSI/ETSI TR1260, 1B
HP1-38-1260-2A ODU, HP 38Ghz, ANSI/ETSI TR1260, 2A
HP1-38-1260-2B ODU, HP 38Ghz, ANSI/ETSI TR1260, 2B
* Frequencies shown are NOT center frequencies, but rather the edge of the transmit band.
Center frequency limits are 1/2 the channel bandwidth away from these numbers.
Trango Systems, Inc.
Description
GigaPlus User Manual Rev 3.1
TX Freq TX Freq Diplexer
Min* Max* Range
(MHz) (MHz) (MHz)
24,250 24,450 200
25,050 25,250 200
24,250 24,450 200
25,050 25,250 200
24,549 24,871 322
25,557 25,879 322
24,843 25,151 308
25,851 26,159 308
25,123 25,445 322
26,131 26,453 322
24,549 24,885 336
25,557 25,893 336
24,829 25,165 336
25,837 26,173 336
25,109 25,445 336
26,117 26,453 336
27,520 28,025 505
28,528 29,033 505
27,968 28,473 505
28,976 29,481 505
27,520 28,025 1008
28,528 29,033 1008
27,968 28,473 1008
28,976 29,481 1008
27,500 27,680 450
27,950 28,130 450
27,610 27,790 450
28,060 28,240 450
27,720 27,900 450
28,170 28,350 450
31,815 32,207 392
32,627 33,019 392
32,179 32,571 392
32,991 33,383 392
38,595 38,805 210
39,295 39,505 210
38,795 39,005 210
39,495 39,705 210
38,995 39,205 210
39,695 39,905 210
39,195 39,405 210
39,895 40,105 210
37,044 37,632 588
38,304 38,892 588
37,604 38,192 588
38,864 39,452 588
37,044 37,632 588
38,304 38,892 588
37,604 38,192 588
38,864 39,452 588
Max
Chan
Size
(MHz)
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
