6.2 CDM-760 Front Panel Menus
The primary and nested menus available from the CDM-760 front panel are described in this
section.
The actual choices displayed in the submenus depend on which FAST options are
enabled. Where a FAST option affects a menu, this is explained in the sections that
follow in this chapter.
Menu Branch
Opening Screen
Select (main)
Configuration
Monitor
Test
Store/Ld
Utility
ODU
FAST

Table 6-2. CDM-760 Front Panel Menus

Display
Comtech CDM-760 Advanced High-Speed
Trunking Modem
SELECT: Configuration Monitor Test
Store/Ld 0Utility ODU FAST
CONFIG: NetSpec Tx Rx Intf CnC Comp
DPD Remote IP Mask Ref MEO
Monitor: Live-Alarms Stored-Events ACM
Rx-Params CnC Stats Buffer MEO DPD
TEST: Mode BERT Comp LED
Configuration #0 thru #9: Load Store
Utilities: Set-RTC Display EventLog
CID AGC 1:1 1:N Circuit-ID Firmware
ODU: BUC PwrSupply+Ref (FUTURE)
LNB PwrSupply+Ref FSK-control (FUTURE)
FAST: Options Demo-Mode CnC
Description
Press ENTER to access the SELECT:
(main) menu or, from any other screen,
press CLEAR repeatedly to return to this
ver X.X.X screen. This top-level (splash) screen
identifies the modem and its running
firmware version.
Use to access all monitor and control
submenus.
Select to fully configure the modem.
Use to monitor the status of the modem
and view the log of stored events for the
modem.
Use to configure the modem into one of
several test modes or to configure/monitor
the BER Tester.
Use to store and load (recall) up to 10
different modem configurations.
Use to perform miscellaneous functions,
such as setting the Real-Time Clock,
adjusting the display brightness, etc.
When installed and available, use to
configure Outdoor Unit (BUC – Block Up
Converter or LNB – Low-Noise Block
Down Converter) operations.
Use to verify installed options and
configure different Fully Accessible
System Topology options, e.g., extended
data rates, interfaces, etc. Contact
Comtech EF Data Product Support for
details.
