Ethernet Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
7.4.3 HTTP Interface – Menu Tree
The Figure 7-4 menu tree diagram lists the features available through the CDM-760 HTTP
Interface. This interface features four navigation tabs (shown in blue). Primary page tabs (green)
and nested page tabs (yellow) provide access to individual web pages. Click any navigation tab
to continue.
The CDM-760 HTTP Interface pages that are marked with an asterisk (*) are functional
only when you activate the optional FAST feature, or accessible to Admin users when
the optional High-Speed Packet Processor card is installed and enabled. See Sect.
7.4.3.1 for information about using conditional access pages.
Any page marked with double asterisks (**) is functional only when an auxiliary
product such as a PIIC (Plug-In Interface Card) or LNB (Low Noise Block Down
Converter) is installed.
Figure 7-4. CDM-760 HTTP Interface Menu Tree (FW Ver. 1.7.3)
