Appendix H
CDM-760 Advanced High-Speed Trunking Modem
H.2.3 CDM-760 CID Configuration – HTTP (Web Server) Interface
See Chapter 7. ETHERNET INTERFACE OPERATION for in-depth information about
the function and operation of the CDM-760 HTTP Interface.
YOU MAY PROCEED WITH ETHERNET-BASED REMOTE PRODUCT MANAGEMENT
(HTTP OR SNMP) UNDER THE ASSUMPTIONS THAT:
•
The CDM-760 is operating with the latest version firmware files.
•
The CDM-760 is connected to a user-supplied, Windows-based PC, and:
o The PC serial port is connected to the CDM-760 rear panel J3 | REMOTE
o The PC Ethernet port is connected to either the CDM-760 rear panel J4 |
o The PC is running a terminal emulation program (for operation of the
•
The CDM-760 Management IP Address has been noted using the CDM-760
Serial Interface.
Figure H-2 shows the menu tree for the CDM-760 HTTP Interface. Modem operations not specific
to CDM-760 Carrier ID operation appear dimmed in this diagram and are explained in Chapter 7.
This menu tree depicts the CDM-760 HTTP Interface as it appears with all FAST Features activated,
and the optional High-Speed Packet Processor installed and active.
port with a user-supplied serial cable.
MGMT or the Packet Processor P0 | MGMT RJ-45 10/100/1000 BaseT
Ethernet port with a user-supplied hub, switch, or direct Ethernet cable
connection.
CDM-760 Serial Interface) and a compatible web browser (for operation of
the HTTP Interface).
