Appendix B
CDM-760 Advanced High-Speed Trunking Modem
Table B-1. DVBS2, Normal Block, Pilot ON, QEF (PER 10
Min SR
MOD FEC
(Msps)
1/4 0.1
1/3 0.1
2/5 0.1
1/2 0.1
3/5 0.1
QPSK 2/3 0.1
3/4 0.1
4/5 0.1
5/6 0.1
8/9 0.1
9/10 0.1
3/5 0.1
2/3 0.1
3/4 0.1
8PSK
5/6 0.1
8/9 0.1
9/10 0.1
2/3 0.1
3/4 0.1
16APSK 4/5 0.1
5/6 0.1
8/9 0.1
9/10 0.1
3/4 0.1
4/5 0.1
32APSK 5/6 0.1
8/9 0.1
9/10 0.1
Max SR Min DR
(Msps) (Mbps)
150 0.05
150 0.06
150 0.08
150 0.10
150 0.12
150 0.13
150 0.15
150 0.15
150 0.16
150 0.17
150 0.17
120 0.17
120 0.19
120 0.22
120 0.24
120 0.26
120 0.26
90 0.26
90 0.29
90 0.31
90 0.32
90 0.34
90 0.35
72 0.36
72 0.39
72 0.40
72 0.43
72 0.44
B–3
-7
) AWGN Linear Channel
Max DR Spec Eff
(Mbps) (Bits / Hz)
72 0.48
96 0.64
115.5 0.77
144.80 0.97
174.00 1.16
193.70 1.29
217.80 1.45
232.40 1.55
242.30 1.62
258.60 1.72
261.90 1.75
208.80 1.74
232.30 1.94
261.40 2.18
290.60 2.42
310.30 2.59
314.20 2.62
231.80 2.58
260.60 2.90
278.10 3.09
290.00 3.22
309.60 3.44
313.50 3.48
260.90 3.62
278.40 3.87
290.20 4.03
309.80 4.30
313.70 4.36
Revision 4
MN-CDM760
QEF QEF
Eb/No Es/No
0.9 -2.3
0.8 -1.1
0.9 -0.2
1.4 1.2
1.8 2.4
2.2 3.3
2.6 4.2
3.0 4.9
3.3 5.4
4.0 6.4
4.2 6.6
3.4 5.8
3.9 6.8
4.7 8.1
5.8 9.6
6.9 11.0
7.0 11.2
5.2 9.3
5.9 10.5
6.4 11.3
6.8 11.9
7.8 13.2
8.0 13.4
7.5 13.1
8.1 14.0
8.6 14.7
9.8 16.1
10.0 16.4
