Comtech EF Data CDM-760 Installation And Operation Manual page 274

Serial Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
Controller-to-Target
Instruction Code and
Qualifier
Parameter Type
Command Query
Re Center Buffer RCB= N/A
PIIC Rx ASI Mode PRM= PRM?s
PIIC Tx ASI Mode PTM= PTM?s
PIIC Rx ASI PRF= PRF?s
Framing
PIIC Tx ASI PTF= PTF?s
Framing
Arguments for
Description of Arguments
Command or
(Note that all arguments are ASCII numeric codes from 48 to 57)
Query
1 byte Command only.
Force the software to recenter the receive buffer.
s=Interface Slot, where:
1=Slot 1
2=Slot 2
EXAMPLE: <0/RCB=2 (re-centers the buffer on the Slot 2 interface card)
1 byte Command or Query.
(ASI PIIC only) Sets or returns Rx ASI Mode in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Mode, where:
0=Off
1=ASI-Normal
1 byte Command or Query.
(ASI PIIC only) Sets or returns Tx ASI Mode in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Mode, where:
0=Off
1=ASI-Normal
2=ASI- Advanced
1 byte Command or Query.
(ASI PIIC only) Sets or returns Rx ASI Framing in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Framing, where:
0=None
1=TS-188
2=TS-204
1 byte Command or Query.
(ASI PIIC only) Sets or returns Tx ASI Framing in the form sx, where:
s=Interface Slot, where:
1=Slot 1
2=Slot 2
x=Framing, where:
0=None
1=TS-188
2=TS-204
8–31
Revision 3
MN-CDM760
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
RCB= N/A
RCB?
RCB#
RCB*
PRM= PRM=x
PRM?
PRM#
PRM*
PTM= PTM=x
PTM?
PTM#
PTM*
PRF= PRF=x
PRF?
PRF#
PRF*
PTF= PTF=x
PTF?
PTF#
PTF*
