Ethernet Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
7.4.4.3.6

Configuration | Utilities

Use the available text boxes and drop-down lists to configure your settings as needed. Click
[Submit] as applicable to save.
Unless otherwise noted – see Chapter 6. FRONT PANEL OPERATION for detailed
information about the configuration parameters available on this page:
Operational Feature / Section
Circuit ID
Date & Time
Clocks
InBand Modem Control
1:1 Redundancy Control
1:N Redundancy Control
Event Log Style
WAN Buffer Length
Save / Load
Figure 7-22. Configuration | Utilities Page
Chapter 6 Section Reference
6.2.6.7 (Utility:) Circuit ID
6.2.6.1 (Utility:) Set-RTC
6.2.2.10.1 (CONFIG: Ref) Modem Reference
6.2.2.7.2 (CONFIG: Remote) InBand
6.2.6.5 (Utility:) 1:1
6.2.6.6 (Utility:) 1:N
6.2.3.2.1 (Monitor: Stored-Events) Event ###
Use the drop-down list to set the Event Log Style as Fill and Stop or
Fill and Rollover.
6.2.2.2.6 (CONFIG: Tx) WANBuff
6.2.5 SELECT: Store/Ld (Store/Load)
