Ethernet Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
7.4.4.2 Admin (Administration) Pages
The Administrator must use these pages to set up user access, manage the modem's firmware,
and activate FAST options.
The Admin pages are available only when you log in with the Administrator User
Name and Password.
Click the Admin navigation tab, and then select the Access, SNMP, FAST, or Upgrade tab to
continue.
7.4.4.2.1

Admin | Access

The Administrator must use this page to manage the HTTP Interface user access settings.
Modem IP Maintenance
•
Use the Ping Reply drop-down list to select Enabled or Disabled:
Selecting Enabled causes the CDM-760 to reply to ping requests.
o
Selecting Disabled causes the CDM-760 to ignore ping requests and no replies are sent
o
to ping requests.
•
The MAC address for the M&C card on the CDM-760 is read-only.
•
Enter a Session Timeout
on the HTTP Interface. Any activity (configuration changes, mode settings, etc.) resets and
restarts the Session Timeout countdown clock.
•
Enter an IP Gateway destination address. If a response destination IP address is outside of
the CMD-760 M&C subnet, then the CDM-760 forwards M&C responses to this address.
• Enter an IP Address/Range (
Figure 7-7. Admin | Access Page
number, in seconds. This is the time allotted an inactive user session
IP address and subnet mask) for the CDM-760 M&C card.
