Serial Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
Controller-to-Target
Instruction Code and
Qualifier
Parameter Type
Command Query
GE1 Link LC1= LC1?
Configuration
GE2 Link LC2= LC2?
Configuration
Negotiated Port N/A NPS?
Status
Gig Optical LC3= LC3?
Ethernet Interface
Inband Communi- SLC= SLC?
cations
Arguments for
Description of Arguments
Command or
(Note that all arguments are ASCII numeric codes from 48 to 57)
Query
1 byte, value of 0 Command or Query.
thru 6 Sets or returns the GE1 Interface mode in the form x, where:
0=Auto Negotiate (default)
1=1000Mbps Full Duplex
2=100Mbps Full Duplex
3=100Mbps Half Duplex
4=10Mbps Full Duplex
5=10Mbps Half Duplex
6=Off
1 byte, value of 0 Command or Query.
thru 6 Sets or returns the GE2 Interface mode in the form x, where:
0=Auto Negotiate (default)
1=1000Mbps Full Duplex
2=100Mbps Full Duplex
3=100Mbps Half Duplex
4=10Mbps Full Duplex
5=10Mbps Half Duplex
6=Off
2 bytes Query only
Returns GE1/GE2 port status in the form ab, where:
a=GE1 status
b=GE2 status defines as follows:
0=Not Resolved or No Link
1=10 Mbps Half-Duplex
2=10 Mbps Full-Duplex
3=100 Mbps Half-Duplex
4=100 Mbps Full-Duplex
5=1000 Mbps Full-Duplex
EXAMPLE: <0/NPS?
<0000/NPS=55 (1000 Mbps both ports)
1 byte, value of 0 Command or Query.
or 1 Sets or returns the GigE Optical Ethernet Interface mode in the form x, where:
0=Off
1=On
NOTE: Option must be purchased and SFP module installed!
1 byte, value of 0 Command or Query.
or 1 Sets or returns isolation (opening) or connection of the SERDES link between the management Ethernet port and the
data Ethernet ports, in the form x, where:
0=InBand Disabled
1=InBand Enabled
8–24
Revision 3
MN-CDM760
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
LC1= LC1=x
LC1?
LC1*
LC1#
LC2= LC2=x
LC2?
LC2*
LC2#
N/A NPS=ab
LC3= LC3=x
LC3?
LC3*
LC3#
SLC= SLC=x
SLC?
SLC*
SLC#
