Introduction
CDM-760 Advanced High-Speed Trunking Modem
Max ModCod update rate
Configurable parameters
Monitored parameters
1.3.8 DoubleTalk
Operating Mode
Symbol Rate Range
CnC Ratio
Symbol Rate Ratio
Inbound/Outbound frequency
uncertainty
Delay range
Es/No Degradation (dB)
measured at 0.0 dB CnC Ratio
Monitor Functions
CnC Monitor Accuracy

1.3.9 Regulatory Compliance

"CE" as follows:
FCC
RoHS Compliance
Updates to the MODCOD can happen up to 4 times per second (no restriction on distance between
MODCODs)
Minimum and Maximum ModCod
Remote Demodulator Unlock options:
Maintain current ModCod
•
Go to minimum ModCod
•
Es/No Target Margin: 0.0 to 4.5 dB0 in 0.1 dB steps
Modulation Type Impairment selection:
Impairment for QPSK, 8PSK, 16APSK, 32APSK, and 64APSK: 0 to 9.9 dB in 0.1 dB steps
•
Impairment for QPSK ≤ 8PSK ≤ 16APSK ≤ 32APSK≤ 64APSK
•
Tx and Rx ModCods
Local and Remote Es/No: (-3.0 dB to +22.0dB, 0.1dB resolution)
Configuration and monitor menus displaying data rate, modulation and code rate update dynamically
with ModCod
®
Carrier-in-Carrier
Requires the two carriers in a duplex circuit to share a common frequency. Different symbol rates are
allowed.
0.1Msps to 63 Msps
Ratio of Interferer Carrier Power to Desired Carrier Power (in dB). Positive values represent a stronger
Interferer Carrier, and negative values represent a stronger Desired Carrier. Range is +7 dB to -7 dB.
3:1 Tx/Rx or Rx/Tx
±100kHz
0 - 300 ms (230 - 290 ms factory default)
QPSK, 0.3 dB
8-PSK, 0.3 dB
16-APSK, 0.4 dB
32-APSK, 0.6 dB
Delay, in milliseconds
Frequency offset (between outbound interferer and desired inbound): 100 Hz resolution
CnC ratio, in dB (ratio of absolute power, outbound interferer to desired inbound)
± 1.0 dB for symmetric symbol rate
EN 55022 Class A (Emissions)
EN 50082-1 (Immunity)
EN 60950 (Safety)
FCC Part 15 Subpart B
Yes
®
(CnC)
EN 61000-3-2
EN 61000-3-3
EN 61000-4-2
EN 61000-4-4
EN 61000-4-5
1–16
Revision 4
MN-CDM760
EN 61000-4-6
EN 61000-4-8
EN 61000-4-9
EN 61000-4-11
EN 61000-4-13
