CDM-760 Advanced High-Speed Trunking Modem
C.2.4 DVB ASI (Asynchronous Serial Interface) PIIC Module (CEFD P/N
PL-0022015)
Figure C-7. DVB ASI (Asynchronous Serial Interface) PIIC Module Panel
Figure C-10. G.703 E3/T3/STS-1 PIIC Module
Name
ASI-IN
ASI-OUT
Connectors
C–9
Connector Type Description
BNC Data In
BNC Data Out
Revision 4
MN-CDM760
Direction (I/O)
I
O
