Appendix C. OPTIONAL PIIC
(PLUG-IN INTERFACE CARD)
C.1

Overview

The CDM-760 Advanced High-Speed Satellite Modem rear panel features two slots that
accommodate optional PIIC (Plug-in Interface Card) data modules. These modules plug into
either or both of the Interface Option slots located on the rear panel of the CDM-760 chassis
(Figure C-2).
By convention, a modem is Data Communications Equipment (DCE) where Tx data enters the
data interface and Rx data exits. Via the chassis' PIIC module connections, the CDM-760
provides physical and electrical connection between the external terrestrial device and the
internal circuitry of the modulator or demodulator.
While the CDM-760's available optional PIIC modules are usually ordered with the modem, they
are easily field-installed. The available PIIC modules, and reference to their pertinent section in
this appendix, are as follows:
CEFD Kit / Assembly
PL-0000795
KT-0000256
KT-0000257
KT-0000255
PL-0022015
Additional PIIC module data options (e.g., HSSI) will become available upon
request.
Description
G.703 'BNC' E3/T3/STS-1 PIIC Module
SFP OC-3 Single Mode PIIC Module
SFP OC-3 Multi Mode PIIC Module
SFP STM-1 Copper 'BNC' PIIC Module
DVB ASI Asynchronous Serial Interface PIIC
Module
C–1
MODULES
For Details
See Appendix C Sect.
C.2.1
C.2.2
C.2.3
C.2.4
