Ethernet Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
7.4.4.4.2.2

Status | Logs | PP Log

This nested page is accessible only to Admin users when the optional High-Speed
Packet Processor card is installed and enabled. See Sect. 7.4.3.1 for information
about using conditional access pages.
Use this page to view logged events, faults and alarms attributed to the Packet Processor.
Event Logging
• Logging On/Off – Click On or Off to enable or disable event logging.
• Use the Logging Level drop-down list to select Errors Only, Errors and Warnings, or All
Information.
Click [Submit] to execute.
Clear Event Log
Click [Clear Log] to clear the log buffer and remove all event entries. The table then displays a
single event, labeled "Event log cleared."
This page provides a scrollable table of stored events, sorted by occurrence from earliest to
latest. This table displays up to 256 events as follows:
Column
Index
Type
Date
Time
Description
Figure 7-30. Status | Logs | PP Log Page
Description
The event is sequentially numbered.
The Fault/Alarm Type displays here as Informational, Warning, or Error.
The event date displays here in MM/DD/YY format.
The event time displays here in HH:MM:SS format.
This column provides a brief summary of the event.
