Serial Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
8.5.3

Rx Parameters

Controller-to-Target
Instruction Code and
Qualifier
Parameter Type
Command Query
Rx Frequency RFQ= RFQ?
Rx Framing Mode N/A RFM?
Rx ModCod N/A RMC?
Arguments for
Description of Arguments
Command or
(Note that all arguments are ASCII numeric codes from 48 to 57)
Query
9 bytes Command or Query.
Sets or returns Rx Frequency ranges in MHz, in 100Hz steps, in the form xxxx.xxxx where:
xxxx.xxxx=value from 50 MHz to 180 MHz (70/140 MHz), or from 950 MHz to 2150 MHz (L-Band)
EXAMPLE: <0/RFQ=0950.9872
1 byte, value of 0 Query only.
or 1 Returns Rx Framing mode in the form x, where:
0=Normal Block
1=Short Block
NOTE: Not all Network Specs will support both Framing Modes.
EXAMPLE: <0/RFM?
>0000/RFM=1 (Short Block mode)
2 bytes Command or Query.
FOR NET=0: Sets or returns Rx Demodulation in the form xx, where:
00=ACM
01=reserved (QPSK 1/4)
02=reserved (QPSK 1/3)
03=reserved (QPSK 2/5)
04=QPSK 1/2
05=QPSK 3/5
06=QPSK 2/3
07=QPSK 3/4
08=QPSK 4/5
09=QPSK 5/6
FOR NET=1: Sets or returns Rx Modulation in the form xx, where:
00=ACM
01=reserved (QPSK 1/4)
02=reserved (QPSK 53/180)
03=reserved (QPSK 1/3)
04=reserved (QPSK 11/30)
05=reserved (QPSK 2/5)
06=reserved (QPSK 77/180)
07=reserved (QPSK 83/180)
08=QPSK 1/2
09=QPSK 8/15
10=QPSK 17/30
11=QPSK 3/5
12=QPSK 19/30
13=QPSK 2/3
14=QPSK 127/180
15=QPSK 3/4
10=QPSK 8/9 20=16-APSK 4/5
11=QPSK 9/10 21=16-APSK 5/6
12=8PSK 3/5 22=16-APSK 8/9
13=8PSK 2/3 23=16-APSK 9/10
14=8PSK 3/4 24=32-APSK 3/4
15=8PSK 5/6 25=32-APSK 4/5
16=8PSK 8/9 26=32-APSK 5/6
17=8PSK 9/10 27=32-APSK 8/9
18=16-APSK 2/3 28=32-APSK 9/10
19=16-APSK 3/4
16=QPSK 4/5 32=16-ASK 19/30
17=QPSK 5/6 33=16-APSK 2/3
18=QPSK 31/36 34=16-APSK 128/180
19=QPSK 8/9 35=16-APSK 3/4
20=QPSK 9/10 36=16-APSK 4/5
21=8PSK 17/30 37=16-APSK 5/6
22=8PSK 3/5 38=16-APSK 31/36
23=8PSK 19/30 39=16-APSK 8/9
24=8PSK 2/3 40=16-APSK 9/10
25=8PSK 127/180 41=32-APSK 127/180
26=8PSK 3/4 42=32-APSK 3/4
27=8PSK 4/5 43=32-APSK 4/5
28=8PSK 5/6 44=32-APSK 5/6
29=8PSK 31/36 45=32-APSK 31/36
30=8PSK 8/9 46=32-APSK 8/9
31=8PSK 9/10 47=32-APSK 9/10
8–14
Revision 3
MN-CDM760
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
RFQ= RFQ=xxxx.xxxx
RFQ?
RFQ*
RFQ#
RFM? RFM=x
RFM*
RFM#
RMC? RMC=xx
RMC*
RMC#
