Ethernet Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
7.4.4.4.6.4

Status | Traffic Statistics | Router

Use this page to review the activity on the Packet Processor card. These items are generated per
the Packet Processor stack and are used primarily for system and network debugging.
Clear Statistics
•
Click [Clear] to clear/reset the Router statistics buffers.
• Click [Refresh] to update the page with the latest available statistics.
Router Counters
Item
Received Packets
Routed Packets
Figure 7-38. Status | Traffic Statistics | Router Page
Description
Number of packets received by the Packet Processor stack for
routing.
Number of packets the router has found a valid route for since the
statistics buffer wads last cleared. – a large mismatch generally
indicates no default route. A slight mismatch means some packets are
seen as un-routable
This number should roughly match the number of
Received Packets:
• A slight mismatch means some packets are seen
as unroutable.
• A large mismatch generally indicates no default
route.
