Front Panel Operation
CDM-760 Advanced High-Speed Trunking Modem
Use the   arrow keys to select an alphanumeric character to edit, and then use the 
arrow keys to change that character. You may use the following characters:
[Space] (
Press ENTER once you compose your desired Circuit ID string.
6.2.6.8

(Utility:) Firmware

CAUTION
THESE SUBMENUS ARE INTENDED FOR DIAGNOSTIC PURPOSES ONLY. DO NOT CHANGE
AN IMAGE UNLESS OTHERWISE DIRECTED BY COMTECH EF DATA PRODUCT SUPPORT.
These submenus permit you to view information about the CDM-760 internal firmware, or to
select which image is loaded the next time the unit reboots.
Firmware Images: ActiveImage:2
The modem can store two complete firmware images. The read-only top line shows the active
firmware image. On the bottom line, use the   arrow keys to select a parameter. Press
ENTER.

6.2.6.8.1 (Utility: Firmware Images) Info

Firmware Information: ActiveImage:2
The read-only top line shows the active firmware image. On the bottom line, use the   arrow
keys to select Boot-ROM, Image#1, or Image#2. Press ENTER to view the selected firmware
information. Per the following example:
Image #1 Bulk:
FW-0020627-
Use the  arrow keys to scroll through information of all the constituent firmware blocks
that make up the bulk. Press ENTER or CLEAR to return to the previous menu.

6.2.6.8.2 (Utility: Firmware Images) Select

Current Active Image is #1
Next Reboot, will use Image:
The read-only top line shows the active firmware image. This example shows Image #1 as the
Current Active Image.
) *
Info Select
Boot-ROM Image#1
+ - , . / 0-9 and A-Z
Image#2
03/22/13
1.1.1
#1
6–71
Revision 4
MN-CDM760
()
()
()
