Comtech EF Data CDM-760 Installation And Operation Manual page 268

Serial Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
Controller-to-Target
Instruction Code and
Qualifier
Parameter Type
Command Query
GBEI Flow Control GFC= GFC?
GBEI MAC LRN= LRN?
Learning
SNMP Read SRC= SRC?
Community
SNMP SWC= SWC?
Write
Community
SNMP STC= STC?
Trap
Community
SNMP Trap STA= STA?
Destination IP
Address 1
SNMP Trap STB= STB?
Destination IP
Address 2
SNMP SSC= SSC?
System Contact
SNMP SSN= SSN?
Unit Name
SNMP SSL= SSL?
System
Location
Arguments for
Description of Arguments
Command or
(Note that all arguments are ASCII numeric codes from 48 to 57)
Query
1 byte, value of 0 Command or Query.
or 1 Enables or disables flow control in the form x, where:
0=Disable GBEI Flow Control
1=Enable GBEI Flow Control
NOTE: Applies to all ports.
1 byte, value of 0 Command or Query.
or 1 Enables or disables MAC address learning in the form x, where:
0=Disable MAC learning
1=Enable MAC learning
NOTE: Applies to all ports.
1 to 20 bytes, Command or Query.
characters, no Sets or returns SNMP read community string.
spaces NOTE: Empty string is not allowed
EXAMPLE: <0/SRC=public
1 to 20 bytes, Command or Query.
characters, no Sets or returns SNMP write community string.
spaces NOTE: Empty string is not allowed.
EXAMPLE: <0/SWC=private
1 to 20 bytes, Command or Query.
characters, no Sets or returns SNMP traps community string.
spaces NOTE: Empty string is not allowed
EXAMPLE: <0/STC=Comtech
15 bytes Command or Query.
Sets or returns the IP address of the first SNMP Trap destination IP Address 1 where traps will be sent, in the form
xxx.xxx.xxx.xxx.
EXAMPLE: <0/STA=010.006.030.001 (if not configured, returns 000.000.000.000)
15 bytes Command or Query.
Sets or returns the IP address of the SNMP Trap destination IP Address 2 where traps will be sent, in the form
xxx.xxx.xxx.xxx.
EXAMPLE: <0/STB=010.006.030.001 (if not configured, returns 000.000.000.000)
0 to 255 bytes, Command or Query.
characters, Sets or returns SNMP System Contact string.
EXAMPLE: <0/SSC=Joe Net Admin (if not configured, returns empty string: <0/SSC=)
16 bytes, Command or Query.
characters, Sets or returns SNMP System Name string.
EXAMPLE: <0/SSN=Remote1 (if not configured, returns empty string: <0/SSC=)
0 to 255 bytes Command or Query.
Sets or returns SNMP System Location string.
EXAMPLE: <1/SSL=Upstairs back right (if not configured, returns empty string: <0/SSL=)
8–25
Revision 3
MN-CDM760
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
GFC= GFC=x
GFC*
GFC#
LRN= LRN=x
LRN?
SRC= SRC=x
SRC!
SWC= SWC=x
SWC!
STC= STC=x
STC!
STA= STA=xxx.xxx.xx
STA! x.xxx
STB= STB=xxx.xxx.xx
STB! x.xxx
SSC= SSC=x
SSC!
SSN= SSN=x
SSN!
SSL= SSL=x
SSL!
