Comtech EF Data CDM-760 Installation And Operation Manual page 266

Serial Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
Controller-to-Target
Instruction Code and
Qualifier
Parameter Type
Command Query
Retrieve next five
unread Stored
Events (cont.)
Clear All Stored CAE= N/A
Events
Initialize the Stored IEP= N/A
Events Pointer
Event Log Style ELS= ELS?
Management IP IPA= IPA?
Address
Management IPG= IPG?
Default
IP Gateway
Management MAC N/A MAC?
Address
Arguments for
Description of Arguments
Command or
(Note that all arguments are ASCII numeric codes from 48 to 57)
Query
ddmmyy=date stamp.
hhmmss=time stamp.
NOTE: If there are less than five events to be retrieved, the remaining positions are padded with zeros. If there are no
new events, the response is RNE*.
None Command only.
Forces the software to clear the events log.
THIS COMMAND TAKES NO ARGUMENTS.
None Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the stored events log.
THIS COMMAND TAKES NO ARGUMENTS.
1 byte, value of 0 Command or Query
or 1 Sets or returns the EventLog Style in the form x, where:
0=Fill and Stop (DEFAULT)
1=Fill and Roll-over
EXAMPLE: <0/ELS=0 (sets EventLog to Fill and Stop)
18 bytes Command or Query.
Sets or returns the IP Address and network prefix for the 10/100 Base-T Ethernet management port, in the form
aaa.bbb.ccc.ddd.yy, where:
aaa=000-223
bbb=000-255
ccc=000-255
ddd=000-255
yy=network prefix (value from 8 to 31)
EXAMPLE: <0/IPA=010.006.030.001.24
15 bytes Command or Query.
Sets or returns the IP Gateway Address for the Ethernet management port in the form aaa.bbb.ccc.ddd where:
aaa=000-223
bbb=000-255
ccc=000-255
ddd=001-255
EXAMPLE: <0/IPG=010.006.030.001
12 bytes, Query only.
hexadecimal Returns the unique MAC Address for the modem in the form aabbccddeeff.
EXAMPLE: <0/MAC?
<0000/MAC=0006B00001C2
8–23
Revision 3
MN-CDM760
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
CAE= N/A
CAE?
CAE*
CAE#
IEP= N/A
IEP?
IEP#
ELS= ELS=x
ELS?
ELS*
ELS#
IPA= IPA=xxx.xxx.xxx
IPA? .xxx.yy
IPA*
IPA#
IPG= IPG=xxx.xxx.xx
IPG? x.xxx
IPG*
IPG#
N/A MAC=aabbccdd
eeff
