Comtech EF Data CDM-760 Installation And Operation Manual page 142

Front Panel Operation
CDM-760 Advanced High-Speed Trunking Modem
Type Alarm
Unit
PIIC1 ExtClk Out of
(cont.)
Range
PIIC2 ExtClk Act
PIIC2 ExtClk Out of
Range
Log File Fault
Int 250 PLL
Int 900 PLL
MEO Mdm: Mdm
Comms
MEO Over Air comms
MEO ACU Comms
Ethernet Link Down
Tx Internal DAC Clk PLL
(Transmit)
Internal Tx LO PLL
PIIC1 Sym Clk PLL
PIIC2 Sym Clk PLL
PIIC1 Input Signal Low
PIIC2 Input Signal Low
Rx
Demod Unlocked
(Receive)
Rx Level
CnC Unlocked
Internal ADC Clk PLL
EsNo Threshold
Internal Rx LO PLL
PIIC1 Buffer Overflow
PIIC1 Buffer Underflow
State
A PIIC interface has been selected and the clock is set to lock to an
External Clock (as with G.703 or other Synchronous PIIC cards), however
the clock signal does not match the expected clock rate.
A PIIC interface has been selected and the clock is set to lock to an
External Clock (as with G.703 or other Synchronous PIIC cards), however
no clock signal is detected.
A PIIC interface has been selected and the clock is set to lock to an
External Clock (as with G.703 or other Synchronous PIIC cards), however
the clock signal does not match the expected clock rate.
The file that is used to save all logging data regarding modem parameters
is missing or corrupt.
The modem's internal 250MHz clock is out of range or has failed.
The modem's internal 900MHz clock is out of range or has failed.
The modem has been set to run in MEO mode and the communication
between the remote Tx/Rx modem and remote Rx demod is timing out or is
getting corrupt / unexpected.
The modem has been set to run in MEO mode and the communication
between the remote Tx/Rx modem and hub / gateway Tx/Rx modem is
timing out or is getting a corrupt / unexpected response.
The modem has been set to run in MEO mode and the communication
between the remote Tx/Rx modem and the ACU is timing out or is getting a
corrupt / unexpected response.
One or more of the Modem's Gig-E Ethernet ports (J5, J6, J7) is enabled
but the modem does not detect any connection to another device (switch /
router / PC etc.).
The modem's internal DAC clock out of range or has failed
The modem's internal Tx clock out of range or has failed
A PIIC interface has been selected but the symbol clock rate that is being
derived from the data does not match the modem SR programmed.
A PIIC interface has been selected but the symbol clock rate that is being
derived from the data does not match the modem SR programmed.
An OC-3 data interface was selected but the optical SFP module has
determined that the optical signal level is low.
An OC-3 data interface was selected but the optical SFP module has
determined that the optical signal level is low.
Demod is not locked to a signal.
Receive Power Level has tripped AGC alarm point.
Carrier-in-Carrier is enabled but not locked.
The modem's internal ADC clock out of range or has failed
Receive EsNo is below configured alarm point.
Receive Phase Lock Loop fault.
A PIIC interface has been selected but the data rate coming into the PIIC
card exceeds the expected data rate of the user configured PIIC data rate.
A PIIC interface has been selected but the data rate coming into the PIIC
card is less than the expected data rate of the user configured PIIC data
rate.
6–53
Revision 4
MN-CDM760
