Serial Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
8.5.14

Carrier ID

Controller-to-Target
Instruction Code and
Qualifier
Parameter Type
Command Query
Carrier ID Mute MUT= MUT?
Carrier ID Latitude LAT= LAT?
Carrier ID LNG= LNG?
Longitude
Carrier ID Phone PHN= PHN?
Number
Carrier ID Custom MSG MSG?
Message
Arguments for
Description of Arguments
Command or
(Note that all arguments are ASCII numeric codes from 48 to 57)
Query
1 byte, value of 0 Command or Query.
or 1 Sets or returns mute mode in the form x, where:
0=Carrier ID is On.
1=Carrier ID is Off (Muted).
EXAMPLE: <0/MUT=0 (Turns Carrier ID On)
8 bytes Command or Query.
Sets or returns Latitude in the form mmss.ssh, where:
mm=Latitude in Minutes
ss.ss=Latitude in decimal Seconds
h=Hemisphere (N or S).
EXAMPLE: <0/LAT=3325.43N
9 bytes Command or Query.
Sets or returns Longitude in the form mmmss.ssh, where:
mmm=Longitude in Minutes
ss.ss=Longitude in decimal Seconds
h=Hemisphere (E or W).
EXAMPLE: <0/LAT=11158.28W
Variable 1 to 18 Command or Query.
bytes Sets or returns a variable length string denoting Phone Number
String can consist of any of the characters "+0123456789x " (not including ")
'+' and ' ' (Space) are ignored/deleted when sending and 'x' denotes extension.
EXAMPLE: <0/PHN=+18664723963 x123
Variable 1 to 24 Command or Query.
bytes Sets or returns a variable length string with a Custom Message
String can consist of any printable character.
EXAMPLE: <0/MSG=Comtech EFData
8–46
Revision 3
MN-CDM760
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
MUT= MUT=x
MUT?
MUT*
MUT#
LAT= LAT=mmss.ssh
LAT?
LAT*
LAT#
LNG= LNG=mmmss.s
LNG? sh
LNG*
LNG#
PHN= PHN=x
PHN?
PHN *
PHN #
MSG= MSG=x
MSG?
MSG*
MSG #
