Appendix C
CDM-760 Advanced High-Speed Trunking Modem
C.2.4.1 DVB ASI (Asynchronous Serial Interface) PIIC Module – Summary
of Specifications
Item
Data Rate
Framing and Signaling
Jitter
Direction
Connectors
Output Level
Input Level
Diagnostics
Rx Buffer
Description
1 - 216 Mbps
DVB-ASI, 188 and 204 Byte Framing
EN 50083-9
Full duplex, allowing Tx/Rx only operation
BNC-F, 75Ω
800mVpp +/-10%
200mVpp – 880mVpp
• Baseband Loopback (at interface)
• Interface Loopback (through interface module)
0.5 to 75 ms in 0.1 ms steps
C–10
Revision 4
MN-CDM760
