Power Supply

Quantum Scalar i40 and Scalar i80
Top Left Magazine
1,1,5 1,2,5 1,3,5
Front
Bottom Left Magazine
0,1,1 0,2,1 0,3,1
0,1,2 0,2,2 0,3,2
0,1,3 0,2,3 0,3,3
0,1,4 0,2,4 0,3,4
0,1,5 0,2,5 0,3,5
Front
The Scalar i40 and Scalar i80 libraries support single power
configurations consisting of a single AC line input and single DC power
supply. The Scalar i80 library supports a redundant power configuration
consisting of a dual AC line input and dual DC power supplies.
If you have a Scalar i80 and are only using one power supply, the power
supply should be installed in the upper power supply slot, and a filler
plate must cover the empty power supply slot (see
If you are using redundant power, you can hot add or hot swap a power
supply (power to the library remains on while you add or exchange the
hardware).
The Scalar i40 power supply cannot be installed in a Scalar i80. However,
the Scalar i80 power supply works in either the Scalar i40 or the
Scalar i80.
WARNING: The power outlet must be available near the library and
must be easily accessible.
The power system consists of the following components:
• Power supply
• AC power cord
Top Right Magazine
1,4,5 1,5,5 1,6,5
Back
Bottom Right Magazine
0,4,1 0,5,1 0,6,1
0,4,2 0,5,2 0,6,2
0,4,3 0,5,3 0,6,3
0,4,4 0,5,4 0,6,4
0,4,5 0,5,5 0,6,5
Back
Chapter 1: Description
Library Components
1,7,5 1,8,5
Front
0,7,1 0,8,1
0,7,2 0,8,2
0,7,3 0,8,3
0,7,4 0,8,4
0,7,5 0,8,5
Front
Figure 5 on page 11).
