Figure 5 Scalar i80 Back Panel
Components
Standard Features
User Interface
Quantum Scalar i40 and Scalar i80
Half-height FC and SAS tape drives
Tape drive FC cables
This section describes several features of Scalar i40 and Scalar i80
libraries.
The operator panel is located on the front of the library and allows you
to work locally on the library via the user interface. The Web client
allows you to view and perform library functions from remote sites and
is accessible through a browser. The operator panel and Web client each
contain a different user interface and functionality.
Tape drive SAS cables
Ethernet cable in
Chapter 1: Description
Standard Features
Power supply cord
Power supply
filler plate
Service port –
LEFT SCB port
do not use
11
