Chapter 10: Troubleshooting
Interpreting LEDs

Tape Drive/Sled LEDs

Figure 49 SAS Tape Drive LEDs
260
The library supports SAS and Fibre Channel tape drives. The drive sled
LEDs for each are described below.
SAS
SAS Tape Drive Sleds have one LED that indicates the following:
Color Indicates
Green Healthy and operational.
Amber Tape drive is offline.
Red Failure. Replacement required.
Fibre Channel
Fibre Channel tape drive sleds have two LEDs on their rear panel,
indicated on the drive sled as STATUS and LINK (see
LED Color
Status Green
Amber
Red
Status LED
Indicates
Healthy and operational.
Tape drive is offline.
Failure. Replacement required.
Quantum Scalar i40 and Scalar i80 User's Guide
Figure 50).
