Chapter 5: Advanced Reporting
Working with Control Path Failover (CPF)
Figure 17 Tools - Drive
Operations Screen for CPF
Quantum Scalar i40 and Scalar i80 User's Guide
2 Select Force Control Path Failover and click Next.
The Force Control Path Failover screen displays (see
below). All of the partitions that have control path failover enabled
are listed. The location and status of the tape drive that is currently
serving as the control path are listed in the Active columns. The
location and status of the tape drive that is currently serving as the
standby control path are listed in the Standby columns. For each
partition, the following information is listed:
Column
Active Drive
Active Status
Active Connected
Standby Drive
Standby Status
Standby
Connected
Indicates
Location of the current control path tape
drive.
Ready status of the current control path
tape drive.
Whether the current control path tape drive
is connected and has a working link.
Location of the standby tape drive.
Ready status of the standby tape drive.
Whether the standby tape drive is
connected and has a working link.
Quantum Scalar i40 and Scalar i80 User's Guide
Figure 18
