Table 3 Web Client Screen
Elements
Web Client Home Page
Quantum Scalar i40 and Scalar i80 User's Guide
Web Client
Element
Header
Menu bar
Active display
The home page displays status and health information in the active
display portion of the window (see
Summary and Subsystem Status
Chapter 3: Understanding the User Interface
Description
The header is present on all pages and contains
the library type (Scalar i40 or Scalar i80) and three
buttons:
Home — Brings you to the home page.
Help — Displays the online help.
Logout — Logs out of the current session.
A message in the header alerts you when the
robot is not ready to perform library functions.
See Troubleshooting Library "Not Ready"
Messages on page 254 for more information on
"Library Not Ready" messages displayed in the
header.
Displays the available menu choices. The choices
vary depending on login privileges.
The far right of the menu bar also displays the
name of the logged-in user, with the associated
privilege level indicated in brackets.
If a menu item selected has a sub-menu, then >
is displayed to the right of the item.
The active display provides information or menu
items according to the selected menu item or
operation.
Figure 11
below for more information.
Web Client
on page 30). See System
31
