Quantum Scalar i40 and Scalar i80 User's Guide
The full IVT consists of three subtests. You may run the subtests
separately (see Performing Library Diagnostics
takes up to 30 minutes to complete.
• Robotics Test — A series of tests that evaluates the basic
functionality of the robotics assembly, including picker travel,
Y-carriage assembly travel, barcode scanning, calibration sensors,
and several moves of a scratch tape. It also calibrates the robot to
the library. The test takes up to 11 minutes to complete.
• Tape Drive Tes — For each installed tape drive, the robot moves a
t
scratch tape into the tape drive, inventories the scratch tape, and
moves the scratch tape out of the tape drive. The test takes 1–2
minutes per tape drive.
• Magazine Test — Moves a scratch tape through all storage slots in
the library. These tests verify the robotics can reach all the slots in
the magazine for both get and put operations. The test takes up to
5 minutes per magazine.
Details about running the IVT include:
• Running the IVT takes partitions offline and logs all users off of the
Web client.
• The operator panel displays progress of all three subtests. Before a
test begins, its progress is "Scheduled." When a test begins, its
progress changes to "Running." Once a test completes, its progress
changes to either "Passed" or "Failed."
• You can stop the IVT by pressing the Stop button. The progress of
the currently running test changes to "Stopping." Once stopped,
the current test and all other scheduled tests display "Stopped."
• You can only perform the IVT from the operator panel.
Prerequisites for Running IVT
Certain prerequisites must be met in order to run the IVT. Prior to
running the IVT, the library checks to make sure all the prerequisites are
met. If any is not, the operator panel displays a message telling you how
to resolve the issue. Prerequisites include:
• All diagnostic tickets must be closed.
• I/E station slots must be allocated (minimum of five).
Chapter 10: Troubleshooting
Running the Installation and Verification Test (IVT)
on page 268). The full IVT
263
