Chapter 3: Understanding the User Interface
Web Client

System Summary

Subsystem Status

32
The system summary is available on the home page of the Web client.
It provides tabular data on the capacity of the library's partitions, slots,
and tape drives. It also displays whether partitions are online or offline
(in the Storage Slots section). The current user's login privileges
determine which partitions are displayed (see
page 80).
You can quickly gauge the health of the library by observing the color of
the three subsystem status buttons located at the bottom of the home
page. These buttons provide quick access to information about the
"health" of the library for faster recovery if problems occur. You can
select the buttons to view diagnostic tickets that report problems in the
subsystems.
The three subsystems are:
• — Represents connectivity, control, cooling, power, and
Library
robotics.
• — Represents tape drive components, such as tape drives,
Drives
tape drive firmware, and tape drive sleds.
• — Represents media components, such as cartridges and
Media
barcode labels.
Each button has three states indicated by color. The three states are:
Green (check mark)
do exist, they have all been closed.
Yellow (exclamation point)
unopened, low- or high-priority diagnostic tickets.
— The library contains open or unopened urgent
Red ("X" mark)
diagnostic tickets.
If the color of a subsystem button is red or yellow, you can click the
button to display the corresponding
screen lists library, drives, or media tickets, depending on which button
was selected. See About Diagnostic Tickets
information.
— No diagnostic tickets exist, or, if any tickets
— The library contains open or
Diagnostic Tickets
on page 248 for more
Quantum Scalar i40 and Scalar i80 User's Guide
Privilege Levels on
screen. This
