Chapter 1: Description

Library Components

Library Components

Front Panel

Figure 1 Front Panel

2
• Scalar i40 libraries with an LTO-7 drive and any other second drive
require a minimum of 2500 Joules surge suppression circuit on the
AC input line.
• For Scalar i80 libraries with LTO-7 drives, you can use a maximum of
3 drives. This maximum applies even if you are using other drives in
conjunction with the LTO-7 drive, such as using a combination of
LTO-7, LTO-6, and LTO-5 drives.
Figure 1 illustrates the features of the operator panel. The picture shows
the Scalar i40, but the features are the same on the Scalar i80. These
features are described in Table 1.
Quantum Scalar i40 and Scalar i80
Operator panel screen
Navigation/selection
Ticket indicator LED
Power-on LED
Power button
