Appendix A: Specifications

Capacity

Table 9 Library Installed in a
Desktop Kit
Height (with desktop
"feet" installed)
Width
Depth (from library front
bezel to back of library;
excludes drive sleds)*
* Depths listed above exclude drive sleds. Drive sleds will add up to 50 mm to the overall length of
the library depending on tape drive type (half-height, Fibre Channel, SAS). Additionally, when
planning space requirements, take into account installed cables (particularly fibre-optic cable radius
on Fibre Channel tape drives).
Capacity
281
Scalar i40
5.3 in. (135.6 mm)
18.9 in. (480 mm)
31.2 in. (793 mm)
Form Factor
Maximum number of
tape drives
Number of magazines
Number of cartridge
slots
Maximum native
capacity
Number of I/E station
slots
Scalar i40
3U
2 half-height tape drives
2 magazines (20 slots
each
Base unit: 25
Fully licensed: 40
25 slots: 20 TB
40 slots: 32 TB
0, 5, or 20
Quantum Scalar i40 and Scalar i80 User's Guide
Scalar i80
10.6 in. (268.8 mm)
18.9 in. (480 mm)
31.2 in. (793 mm)
Scalar i80
6U
5 half-height tape drives
4 magazines (20 slots
each)
Base unit: 50
Fully licensed: 80
50 slots: 40 TB
80 slots: 64 TB
0, 5, 10, 20, 25, or 40
