Table 1 Front Panel Features
Robotic System and
Barcode Scanner
Quantum Scalar i40 and Scalar i80
Feature Description
Operator The operator panel displays library status
panel screen information and allows you to access the library
menus. These menus allow you to view or change
the library settings and run diagnostic tests. For
more information, see
Four These buttons, in combination with the operator
navigation/ panel display, are used to scroll through screens and
selection select options or commands. The functionality of
buttons these buttons changes depending on the currently
displayed operator panel screen.
Ticket Indicates whether a diagnostic ticket exists on the
indicator LED library. See
Diagnostic Tickets
information.
Power-on LED Indicates whether library power is on or off. See
Front Panel LEDs
Power button Turns the library on or off.
Turning off the library using the power button turns
off the robot and operator panel, but power still
runs to the power supplies. See
Restarting, Turning Off, and Removing Power
page 139 for instructions on how to shut down the
library safely.
The robotic system identifies and moves the cartridges between the
storage slots, tape drives, and the I/E station. The robotic arm (picker)
has picker fingers that enable it to grab tape cartridges and move them
into and out of slots and tape drives.
A barcode scanner is attached to the library's robotic hand. This barcode
scanner automatically identifies the slots and cartridges in the library, if
the cartridges are fitted with acceptable barcode labels.
Each tape cartridge must contain a unique, matching-readable barcode
that the barcode scanner reads during the inventory process. During the
inventory process, the barcode scanner reads the barcode labels on the
