Running the IVT Diagnostic Subtests Individually –
Robotics, Tape Drive, and Magazine Tests
Quantum Scalar i40 and Scalar i80 User's Guide
Running the IVT Diagnostic Subtests Individually – Robotics, Tape Drive, and Magazine Tests
• A scratch tape must be in the top I/E station slot. The scratch tape
must be assigned to the System partition. The scratch tape must be
compatible with all unloaded tape drives installed in the library. For
a list of supported media, see
Operator Panel
1 Make sure the prerequisites listed in
on page 263 are met.
2 Select Tools > IVT.
A message displays, telling you that partitions will be turned offline
and all Web client users will be logged out.
3 Press Yes to set partitions offline, log users off the Web client, and
continue with the test.
The library conducts a series of prerequisite checks to be sure
everything is in order. Each prerequisite is listed as the library checks
it. If something is not set up correctly to run the IVT, the operator
panel displays a message letting you know how to fix it. Once you
fix the issue, again select Tools > IVT. If all is in order, the test
begins.
4 When the test completes, if any of the three subtests fails, check the
library diagnostic tickets to help determine and resolve the problem.
If you do not need to run the full IVT, you can run the robotics, tape
drive, or magazine test separately to check an individual component.
You should do this when you remove, replace, or service a component
that does not require you to remove the library into or out of a rack or
desktop kit.
For a description of the diagnostic subtests, see
and Verification Test (IVT)
Chapter 10: Troubleshooting
Supported Media
Prerequisites for Running IVT
on page 262.
on page 286.
Running the Installation
265
