Beginning a Design
About Designs and Projects
Creating a Project
© National Instruments Corporation
The following sections explain how to start a design in Ultiboard.
Some of the described features may not be available in your edition of
Ultiboard. Refer to the NI Circuit Design Suite Release Notes for a list of
the features in your edition.
Designs are stored inside projects, allowing you to group them together for
easy access. In this way, all designs that have a logical connection between
them (that is, they may all relate to a specific project) are conveniently
located in one file.
Complete the following steps to create a new project file:
1.
Choose File»New Project. The New Project dialog box appears.
2.
Type the project name in the Project name field.
3.
From the Design type drop-down list, select PCB Design. The other
option allows you to use Ultiboard's CAD capabilities (for example,
front panels, enclosures). Refer to the
for more information about these capabilities.
4.
Indicate the folder where the file is to be kept. Either accept the default
shown in the Location field, or click the browse button to select a
different location.
5.
Click OK. The New Project dialog box disappears, and a blank design
is opened, with the same name as that of the project file. The file you
just created is also shown in the Projects tab of the Design Toolbox,
along with its corresponding design.
Using Mechanical CAD
2-1
2
section
NI Ultiboard User Manual
