Appendix A
Menus and Commands
View Menu
View»Full Screen
View»Redraw Screen
View»Zoom In
View»Zoom Out
View»Zoom Window
View»Zoom Full
View»Clearances
View»Grid
NI Ultiboard User Manual
The subjects in this section describe the commands found in the View
menu.
Use to fill the screen with the design only (hide menus, toolbars, other
windows). Click the Close Full Screen button to return to normal view.
Use to refresh the screen.
Use to zoom in to see more details.
Use to zoom out to see more of the design.
Use to magnify a selected part of the board. Use this command when you
want precise control over the workspace view.
Use to return to the full view of the design after zooming in or out. Ctrl-F7
zooms out so that the entire design is visible and centered. This includes the
board outline and any objects that may be either inside or outside the board.
F7 zooms out so that the board is visible and centered. Any objects outside
the board outline will be outside the visible region.
Use to toggle the clearances around pads, traces and other objects on and
off. Refer to the
Placing Traces
and
Copper, for more information.
Use to toggle the visual grid on and off.
section of Chapter 5,
A-8
Working with Traces
ni.com
