Adding and Removing Teardrops

Viewing and Editing Copper Properties

© National Instruments Corporation
A teardrop is a flair that you can add to a trace where the trace connects to
a pad. This is typically used with very small sized traces, to prevent
possible breakage in the copper between the trace and the pad.
Complete the following steps to add teardrops:
1.
Select Design»Add Teardrops. The Teardrops dialog box displays.
2.
Select the Units for the teardrop length.
3.
In the Length box, enter the Preferred and Minimum length for the
teardrops. The preview area changes as the lengths are changed.
4.
In the Apply to box, select the following as desired:
Selected pads radio button—Teardrops will be added to the pads
that are currently selected on the workspace.
All of the following radio button—When selected, enables the
SMT pins, THT pins and Standard vias checkboxes; check as
desired.
5.
In the On DRC error box, select the desired radio button. Choices are
Do not create teardrop; Ask for confirmation; Create teardrop.
6.
Enable or disable the Ignore pad without net checkbox as desired.
7.
Click OK to add the teardrops are added.
To remove all teardrops select Edit»Copper Delete»All Teardrops.
All copper elements (traces, copper areas, and powerplanes) share the same
three properties tabs (Attributes, General, and Position). The fourth tab
for traces is Line, and the fourth tab for copper areas and powerplanes is
Copper Area.
The General tab is where you edit the properties of the selected copper
element.
Complete the following steps to edit the contents of the General tab:
1.
In the Measurements box, set the desired Width. Net shows the net
to which the element is connected, if any. It is read-only.
2.
In the Autorouter Settings box, select either Trace is Fixed or Trace
can be Moved. User-placed traces are fixed (default setting) so that
they will not be moved when autorouting is performed.
Chapter 5
5-13
Working with Traces and Copper
NI Ultiboard User Manual
