Spreadsheet View

The buttons do not appear in all tabs.
Note
© National Instruments Corporation
The Spreadsheet View allows fast advanced viewing and editing of
parameters including part details such as footprints, Reference Designators,
attributes and design constraints.
By default, the Spreadsheet View does not appear until you have
opened a project. To toggle the Spreadsheet View on and off, select
View»Spreadsheet View.
The following buttons are available in the Spreadsheet View.
Button
Export to Textfile button. Displays a standard Windows
Save dialog where you save the selection as a textfile.
Export to CSV File button. Displays a standard
Windows Save dialog where you save the selection as a
file with comma-separated values.
Export to Excel button. Click to open a Microsoft
spreadsheet with the selected data displayed. (You must
have Excel installed to use this function).
Sort Ascending button. Sorts the selected column in
ascending order.
Sort Descending button. Sorts the selected column in
descending order.
Print button. Prints the data in the selected tab.
Select All button. Selects all elements in the tab.
Copy button. Copies the selection to the clipboard.
