INSTALLATION GUIDE

PCI/PXI Gigabit Ethernet Adapters
Installing Your PXI Board
National Instruments gigabit Ethernet adapters are based on the
Intel 82540-compatible Ethernet controller.
This document explains how to install and troubleshoot the Ethernet drivers
for your PCI/PXI board. Some boards also contain additional functionality
(for example, GPIB). Refer to the documentation that came with your kit to
install the software for the other functionality.
Complete the following steps to install the Ethernet adapter:
1.
Shut down Windows, if it is running, by selecting Start»Shut Down.
2.
Power off your PXI or CompactPCI chassis. Keep the chassis plugged
in so that it remains grounded as you install the adapter.
3.
Remove the filler panel from a PXI peripheral bus master slot. The
adapter requires a bus master slot to take advantage of the onboard
DMA and Ethernet controllers. All PXI chassis and most CompactPCI
chassis contain only bus master slots. Refer to your chassis
documentation to verify you are using a bus master slot.
4.
Touch a metal part on your chassis to discharge any static electricity
that might be on your clothes or body.
5.
Insert the adapter into the selected bus master slot. Use the
injector/ejector handle to fully inject the device into place.
6.
Screw the front panel of the adapter to the front panel mounting rail
of the PXI or CompactPCI chassis.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gigabit Ethernet Adapters and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for National Instruments Gigabit Ethernet Adapters

  • Page 1: Installation Guide

    INSTALLATION GUIDE PCI/PXI Gigabit Ethernet Adapters National Instruments gigabit Ethernet adapters are based on the Intel 82540-compatible Ethernet controller. This document explains how to install and troubleshoot the Ethernet drivers for your PCI/PXI board. Some boards also contain additional functionality (for example, GPIB).
  • Page 2: Connect The Network Cable

    Complete the following steps to install the Ethernet adapter: Connect the Network Cable Complete the following steps to connect the network cable: PCI/PXI Gigabit Ethernet Adapters Installation Guide Shut down Windows, if it is running, by selecting Start»Shut Down. Power off the computer and unplug the power cord.
  • Page 3: Install The Drivers

    To configure Ethernet for your adapter, continue with the procedure specific to your operating system outlined later in this guide. Windows Me/98 Windows 2000/XP Windows NT 4.02 PCI/PXI Gigabit Ethernet Adapters Installation Guide...
  • Page 4: Windows Me

    Windows Me/98 Complete the following steps to install the drivers: PCI/PXI Gigabit Ethernet Adapters Installation Guide Shut down, then power off the computer, as shown in the following figure. Install the hardware and cables, then power on the computer, as shown in the following figure.
  • Page 5 Windows automatically detects the new hardware and displays an Add New Hardware Wizard window, as shown in the following figure. Insert the PCI/PXI Gigabit Ethernet Adapters CD-ROM and follow the instructions presented. Choose the Recommended options when given a choice and click Next.
  • Page 6 If Windows displays a dialog box saying it cannot locate the file on the Intel PRO Adapter CD-ROM, insert the PCI/PXI Gigabit Ethernet Adapters CD-ROM and tell Windows to copy files from the d:\Win98Me\ If Windows displays a dialog box indicating it cannot locate a file on the Windows 98...
  • Page 7 Complete the following steps to install the drivers: © National Instruments Corporation Restart the computer as shown in the following figure, then connect to your network. Shut down and power off the computer, as shown in the following figure. PCI/PXI Gigabit Ethernet Adapters Installation Guide...
  • Page 8 Windows automatically detects the new hardware and displays a Found New Hardware Wizard window, as shown in the following figure. Insert the PCI/PXI Gigabit Ethernet Adapters CD-ROM and follow the instructions presented. Choose the Recommended options when given a choice.
  • Page 9 Windows automatically detects the new hardware and displays a Found New Hardware Wizard window, as shown in the following figure. Insert the PCI/PXI Gigabit Ethernet Adapters CD-ROM and follow the instructions presented. Choose the Recommended options when given a choice and click Next.
  • Page 10: Windows Nt

    If Windows displays an Insert Disk dialog box or indicates it cannot locate a file on the Intel PRO Adapter CD-ROM, insert the PCI/PXI Gigabit Ethernet Adapters CD-ROM and tell Windows to copy files from the (typically d:\Win2kXP\ Windows NT 4.02...
  • Page 11 Select Start»Settings»Control Panel»Network»Adapters and click Add, as shown in the following figure. Click Have Disk and insert the PCI/PXI Gigabit Ethernet Adapters CD-ROM. You may also be prompted for the original Windows NT CD-ROM. PCI/PXI Gigabit Ethernet Adapters Installation Guide...
  • Page 12 Networking support. If Windows displays an Insert Disk dialog box or indicates it cannot locate a file on the Intel PRO Adapter CD-ROM, insert the PCI/PXI Gigabit Ethernet Adapters CD-ROM and tell Windows to copy files from the...
  • Page 13: Windows Nt Troubleshooting

    PROSet, double-click the PROSet icon in the Windows Control Panel. To run diagnostics, select the adapter and click the Diagnostics tab, then click Run Tests. If you do not see the ProSet icon, refer to the Troubleshooting Tools section. PCI/PXI Gigabit Ethernet Adapters Installation Guide Additional...
  • Page 14 10. Follow the instructions given previously in the Adapter Cannot Connect to the Network LED Color Function Green Action/Link Yellow/Green Speed PCI/PXI Gigabit Ethernet Adapters Installation Guide Open Windows Explorer. Select Views»Folder Options. Select the View tab. Select Show all files and click OK. Delete net557.inf net557.pnf Double-click the System icon from the Control Panel.
  • Page 15 Try reseating the adapter in the PCI/PXI slot or try a different slot. The network drivers may be corrupt or missing. Try removing and reinstalling the drivers. Try rebooting the computer. Try another cable. Try a different adapter. PCI/PXI Gigabit Ethernet Adapters Installation Guide PCI/PXI Installation Additional Troubleshooting Tools...
  • Page 16: Additional Troubleshooting Tools

    • • • Additional Troubleshooting Tools The PCI/PXI Gigabit Ethernet Adapters CD-ROM contains an Intel utility for troubleshooting the gigabit Ethernet adapter. Complete the following steps to install the tool: PCI/PXI Gigabit Ethernet Adapters Installation Guide Make sure you have installed the adapter in a bus master-enabled slot.
  • Page 17: Ethernet Adapter Specifications

    National Instruments™, NI™, NI-488.2™, and ni.com™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.
