Chapter 1 User Interface

Spreadsheet View: Nets Groups Tab

NI Ultiboard User Manual
Use the Net Groups tab to work with net groups.
Column
Net Group This is the group in which the net is contained. You
can either enter the group name here, or use the Group
Editor. Refer to the
section of Chapter 3,
information.
Trace Width The "default" width of the traces in the group that are
placed during routing. You can enter a value here, or
use the Group Editor. Refer to the
Group Editor
section for more information.
Max Width The maximum width to which a trace in the group will
be laid during routing. You can enter a value here, or
use the Group Editor. Refer to the
Group Editor
section for more information.
Min Width The minimum width to which a trace in the group will
be laid during routing. You can enter a value here, or
use the Group Editor. Refer to the
Group Editor
Design, for more information.
Max Length Maximum allowable length of copper in a net group.
Not applicable (N/A) if Topology is set to Shortest.
Min Length MInimum allowable length of copper in a net group.
Not applicable (N/A) if Topology is set to Shortest .
Trace This is the minimum spacing allowed between the
Clearance traces in the group and any other trace. You can enter
a value here, or use the Group Editor. Refer to the
Working with the Group Editor
Up a
Routing The routing layers assigned to this net group. Click to
Layers display the Layers to Apply dialog box, where you
set the layers to use for routing copper.
Description
Working with the Group Editor
Setting Up a
of Chapter 3,
of Chapter 3,
section of Chapter 3,
Design, section for more information.
1-38
Design, for more
Working with the
Setting Up a Design,
Working with the
Setting Up a Design,
Working with the
Setting Up a
of Chapter 3, Setting
ni.com
