Note
You cannot assign a net to more than one group. Therefore, nets that are already
assigned to another net group do not appear in the Assign Nets list.
Refer to the
Note
more information.
Working with Part Groups
Note
Refer to the
more information.
© National Instruments Corporation
8.
Click checkboxes beside the desired nets in the Assign Nets list and
click Apply to add them to the group.
9.
Click OK to close the Edit Groups dialog box.
Complete the following steps to edit a net group:
1.
Select Tools»Group Editor to display the Edit Groups dialog box.
2.
Select the Net Groups tab.
3.
Highlight the desired group in the Groups list.
4.
Change the net assignments as desired and click Apply.
5.
Optionally, highlight the desired group in the Groups list and click the
Properties button to display the Change group settings dialog box.
6.
Make the required changes in the Group Settings area and click OK.
Change Group Settings dialog box
Complete the following steps to delete a group:
1.
Select Tools»Group Editor to display the Edit Groups dialog box.
2.
Select the Net Groups tab.
3.
Highlight the desired group in the Groups list and click Delete.
Complete the following steps to create a part group:
1.
Select Tools»Group Editor to display the Edit Groups dialog box.
2.
Click the Part Groups tab.
3.
Click Add. The Add group dialog box appears.
4.
Enter the desired name and click OK. The Change group settings
dialog box appears.
5.
Change the settings in the Group Settings area as desired.
Change Group Settings dialog box
and
Net Group Settings
and
Part Group Settings
3-13
Chapter 3
Setting Up a Design
sections for
sections for
NI Ultiboard User Manual
