Wizard Toolbar

Autoroute Toolbar

NI Ultiboard User Manual
Button
Polygon Splitter button. Splits copper areas and
powerplanes. Refer to the
Chapter 5,
information.
Remove Copper Islands button. Removes copper
islands. Refer to the
Chapter 5,
information.
The Wizard toolbar contains the wizard functions supported by Ultiboard.
The Wizard toolbar buttons are explained in the table below.
Button
Board Wizard button. Starts the Board Wizard. Refer to
the Working with the Board Outline
Setting Up a
Part Wizard button. Starts the Part Wizard. Refer to the
Using the Part Wizard to Create a Part
Chapter 4,
The Autoroute toolbar contains the autorouting and placement functions
supported by Ultiboard. The Autoroute toolbar buttons are explained in the
table below.
Button
Begin Autoplacing button. Starts automatically placing
parts.
Autoroute Selected Buses button. Displays the Bus
Autorouting dialog.
Start Trace Optimization button. Starts trace
optimization.
Description
Splitting Copper
Working with Traces and
Placing Copper Areas
Working with Traces and
Description
Design, for more information.
Working with Parts, for more information.
Description
1-12
section of
Copper, for more
section of
Copper, for more
section of Chapter 3,
section of
