Appendix A Menus and Commands
Help»About Ultiboard

Context Menus

Select Menu

NI Ultiboard User Manual
Use to display the version numbers of your copy of Ultiboard.
Depending on the action, the following context sensitive menus display
when the right mouse button is clicked:
• Select Menu
• Right-drag Menu
• Place Trace Menu
When you select an object or objects in a design and then right-click your
mouse, a context menu with the following options displays.
Cut
Removes the selected element(s) from the board. Element is placed on the
Windows Clipboard and can be pasted again.
Paste
Pastes the item on the Windows Clipboard to its original layer (regardless of
what layer is currently active). Creates new duplicate object(s) without the
netlist information. New parts will have Reference Designators that increment
from the next available for that part type. For example, if the last resistor was
R34, and a resistor is pasted, its Reference Designator will be R35.
Copy
Copies the selected elements and stores them on the Windows Clipboard so
they can be pasted again.
Delete
Deletes the selection from the design.
Select All
Selects all items on the design.
Select Entire Trace
Use to select a whole trace when one or more segments of the same trace
are selected.
