Chapter 4
Working with Parts
When you place parts from the database you must add them to the netlist. Refer to the
Tip
Using the Netlist Editor
information.
NI Ultiboard User Manual
•
Zoom In button—Click to zoom in on the part for more detail.
You can also press the F8 key.
•
Zoom Out button—Click to zoom out. Shows less detail and
more of the whole part. You can also press the F9 key.
•
Zoom Window button—Click (or press <F6>) and then drag a
rectangle around the portion of the part you want to enlarge. The
area inside the rectangle enlarges to fill the Preview panel.
•
Zoom Full button—Click to view the entire part. You can also
press <Ctrl-F7>.
•
Mouse Wheel—If your mouse has a center wheel, you can use it
to zoom in and out on the part.
•
Scroll bars—When the part has been enlarged beyond the borders
of the
Preview
usual manner to locate the desired section of a part.
4.
Click OK. The Get a part from the Database dialog box disappears,
and the Enter Reference Designation for Part dialog box appears.
5.
Enter the part's REFDES (Reference Designator) and Value (for
example, 20 ohms for a resistor) and click OK.
6.
Move the pointer over the board. The selected part is attached to the
pointer.
7.
When the part is in position, click to drop it on the board.
8.
Optionally, adjust or move the part further into position. Refer to the
Tools to Assist Part Placement
section of Chapter 5,
area, scroll bars appear that you can move in the
section for more information.
Working with Traces and
4-28
Copper, for more
ni.com
