Working with the Group Editor
Add Group dialog box
© National Instruments Corporation
•
Pin "[Pin number]" from Part "[refdes]"(value) in Net "[Net
name]" is missing from shape "[shape name]"— A pin belonging to
the specified part was given in the netlist but does not exist in the shape
that was given for the part.
•
Unused Pin [Pin name] is {close to, connected to} {Unused Pin,
Copper}—The given pin that was not assigned to a net is close to or
connected to another unused pin or copper, for example, a trace,
powerplane, or copper area.
•
Design Rule Error: Net [Net1 name] { connected to} { Net2 name,
Unused pin, copper, Board outline }—The given net was connected
to another net, an unused pin, copper or the board outline.
•
Design Rule Error: Net Gnd Close to Net [Net name]
[RefID:PIN#-netname]—The given net was too close to another net.
You can set up whether the design rule check runs in "real time", and define
the actions to be taken when Ultiboard encounters a design rule error, such
as cancelling the current action, asking for confirmation, or overruling the
error. Refer to the
PCB Design Tab
more information.
The Edit Groups dialog box is where you create and edit net groups, part
groups, bus groups and differential pairs.
Refer to the following sections for more information:
•
Add Group dialog box
•
Working with Net Groups
•
Working with Part Groups
•
Working with Bus Groups
•
Working with Differential Pairs
Use the Add group dialog box to create groups in the Edit Groups dialog
box. Refer to the following subjects for more information:
•
Working with Net Groups
•
Working with Part Groups
•
Working with Bus Groups
•
Working with Differential Pairs
section of Chapter 1,
3-11
Chapter 3
Setting Up a Design
User
Interface, for
NI Ultiboard User Manual
