Real-Time Pin/Gate Swapping

Note For this feature to function, you must allow pin/gate swapping in the Spreadsheet
View, and allow real-time swapping in the Design Rules tab of the PCB properties dialog
box.
© National Instruments Corporation
This feature allows you to swap pins and/or gates automatically in real-time
as you move parts on the workspace.
