Device Control

Outputs
You can access

Device Control

Output # 1 Pulse
Definition: Activates the link between Output 1 (+) and Output 1 (–) of the host con-
nector for the duration set by
of Master Symbol or Output 1 status).
ESP: Click
Serial Cmd: <L1>
Output # 2 Pulse
Definition: Activates the link between Output 2 (+) and Output 2 (–) of the host con-
nector for the duration set by
of Master Symbol or Output 2 status).
ESP: Click
Serial Cmd: <L2>
Output # 3 Pulse
Definition: Activates the link between Output 3 (+) and Output 3 (–) of the host con-
nector for the duration set by
of Master Symbol or Output 3 status).
ESP: Click
Serial Cmd: <L3>
from the Utilities menu.
Output # 1 Pulse to activate.
Output # 2 Pulse to activate.
Output # 3 Pulse to activate.
"Pulse Width" on page
"Pulse Width" on page
"Pulse Width" on page
MS-3 Laser Scanner User's Manual
Chapter 11 Utilities
6-19. (regardless
6-19. (regardless
6-19. (regardless
11-13
