Microscan MS-3 User Manual page 50

RS-232 Auxiliary Port
Parity, Aux Port
Usage: Only changed if necessary to match host setting.
Definition: An error detection routine in which one data bit in each character is set to
1 or 0 so that the total number of 1 bits in the data field is even or odd.
Default: Even
Options: <K101,aux port mode,baud rate,parity,stop bits,data bits,daisy chain
ID status,daisy chain ID>
Serial Cmd: 0 = None
Stop Bits, Aux Port
Usage: Only changed if necessary to match host setting.
Definition: Allows the user to select the last one or two bits in each character to indi-
cate the end of the character.
Serial Cmd: <K101,aux port mode,baud
ID status,daisy chain ID>
Default: One
Options: 0 = One
Data Bits, Aux Port
Usage: Only changed if necessary to match host setting.
Definition: Number of bits in each character.
Serial Cmd: <K101,aux port mode,baud rate,parity,stop
ID status,daisy chain ID>
Default: Seven
Options: 0 = Seven
MS-3 Laser Scanner User's Manual
3-12
1 = Even
rate,parity,stop
1 = Two
1 = Eight
2 = Odd
bits,data bits,daisy chain
bits,data bits,daisy chain
