Step 1 — Hardware Required
Caution: If using your own power supply (see
page i-xi), be certain that it is wired correctly and supply voltage is 10 to 28 VDC.
Incorrect wiring or voltage can cause software or equipment failures.
If connecting to a host with an IB-131 Interface box, you will need the following:
a
Item Part Number
1 FIS-0003-1XXX
2 FIS-0001-0029
3 99-400005-02
4
5 P/N 61-300026-01
97-100004-05 (120VAC)
6
97-100004-06 (240VAC)
7 99-4400001-10
a. See figure 1-1
4
MS-3 Laser Scanner User's Manual
1-2
MS-3 laser scanner
IC-331 Interface converter
IB-131 Interface box
Host computer
Null modem configuration cable
Power supply
Optional object detector
for diagram of system.
3
Scanner
5
6

Figure 1-1 Hardware Required

"Warning and Caution Summary" on
Description
1
2
7
